Airflex TRIO

The AirFlex® Trio is a brilliant and innovative, yet cost effective, 3 cell-cycle alternating pressure air mattress designed to prevent pressure injuries in vulnerable patients at High to Very High Risk of pressure injury development.

The mattress features advanced solenoid technology to facilitate the rapid redirection of airflow which enables the effective off-loading of interface pressure on vulnerable tissue. Cell-in-cell construction improves patient comfort and safety by providing a permanently inflated base portion beneath the active alternating component of the air cell.

A comfort setting reduces internal mattress pressure for frail and underweight patients (<45 kg) and static mode provides a firm and stable surface for essential nursing procedures such as physiotherapy, wound dressing and changing bed linen. Transport mode ensures the mattress remains inflated for 8 hours in the event of a mains power failure.

Advanced engineering and a quality compressor have created a dynamic support surface that is therapeutic for patients weighing up to 220 kg.

Airflex Trio

https://www.traditionrolex.com/16
3-cell 15 minute cycleProvides regular relief of interface pressure.
Wide diameter tubingEnables rapid air cell deflation 4 times per hour which stimulates reactive hyperaemia in the deep tissues surrounding the vulnerable bony prominences.
Cell-in-Cell technologyImproves patient comfort and safety by providing a permanently inflated base portion beneath the active alternating component of the cell.
Fully automatic adjustmentAutomatically adjusts pressure settings in response to patient weight and position to optimise pressure relief and ensure that staff are not burdened with difficult product set-up.
Dual comfort settingsAdjustable comfort control available within both Static and Dynamic modes provide nursing staff with the ability to adjust air cell inflation pressures to suit individual patient comfort or clinical requirements.
Easily accessible CPR facilityIntuitive, always visible and accessible CPR release valve located on umbilical provides rapid deflation.
Timed Static modeProvides a firm and stable surface for essential nursing procedures such as physiotherapy, wound dressing and changing bed linen. A safety automatic return to Dynamic mode after 30 minutes ensures that patients are not put at risk of pressure damage.
Transport modeEnsures the mattress remains inflated for 8 hours in the event of a mains power failure.
V-Lock systemPrevents accidental disconnection of the power cord.
Audible and visual alarmsA sophisticated set of audible and visual alarm functions provide enhanced patient safety and ensures peace of mind.
Waterproof, vapour permeable, Dartex® coverProvide microclimate control at the skin/mattress interface.
Soft, easy to clean cover with 360° zipCan be easily removed for infection control and contains an antimicrobial agent that can withstand high temperature washing.
Risk CategoryHigh to Very High Risk
Max Patient Weight220kg
Mattress DimensionsSingle: 1900mm x 880mm x 200mm (standard)

King Single: 2050mm x 1050mm x 200mm

Extra Long: 2050mm x 880mm x 200mm

Special Order Only1900mm x 800mm x 200mm (narrow)
Power Unit Dimensions400mm x 160mm x 250mm
Product WeightMattress: 9.2kg Power unit: 2.8kg
Cycle Time15 Minutes (1-in-3 cell cycle)
Cycle ControlMicroprocessor controlling solenoid valves
Power Supply / Consumption230 V~ ±10%, 50 / 60 Hz 20 W max
ClassificationClass B Medical Device / Class II
Warranty2 years
